Operating Instructions
Fig. 3-23 Rocker Switch Combination
S/N5: work light switch. Press the switch downward in direction A as shown in the Fig. 3-21 to turn on the
switch. At this time, the rear lights of the entire vehicle are all on;
Press the switch downward once in direction B as shown in the Fig. 3-21 to turn off the switch;
Press the switch once again downward in direction B as shown in the Fig. 3-21 to turn on the
switch function. However the rear light of the entire vehicle is not on;
Horn switch
The horn switch is in the middle of the steering wheel. Press the horn button shown in the figure to turn on the
horn switch.
Fig. 3-9 Horn Switch
5
23
