S/N1: PTO switch, which has a built-in limit function. Press the limit downward, and press the switch
downward in direction A as shown in the Fig. 3-21 at the same time to turn on the switch;
Press the switch downward in direction B as shown in the Fig. 3-21 to turn off the switch.
S/N2: park regeneration switch. After parking, press the switch and hold for 3s to turn on the DPF regeneration
function;
Press the switch downward in direction B as shown in the Fig. 3-21 to turn off the switch.
Rocker Switch Combination on Instrument Panel on Models with a Cab
Fig. 3-22 Rocker Switch Combination
S/N3: work light switch. Press the switch downward in direction A as shown in the Fig. 3-21 to turn on the
switch. At this time, the top light and rear light of the entire vehicle are all on;
Press the switch downward once in direction B as shown in the Fig. 3-21 to turn off the switch;
Press the switch once again downward in direction B as shown in the Fig. 3-21 to turn on the rear light
of the entire vehicle;
S/N4: front wiper switch. Press the switch downward in direction A as shown in the Fig. 3-21 to turn on the
switch. At this time, the front wiper works in high gear;
Press the switch downward once in direction B as shown in the Fig. 3-21 to turn off the switch. At this
time, the front wiper stops working;
Press the switch once again downward in direction B as shown in the Fig. 3-21 to turn on the switch.
At this time, the front wiper works in low gear;
Rocker Switch Combination on Instrument Panel on Models with Safety Frames
