Operating Instructions
Important:
1. In case that the hydraulic output device is not in use, the joint seat shall be covered with a sealing cover
to avoid dust.
2. Lifter and hydraulic output valve cannot be used simultaneously;
3.After the hydraulic output device is operated, the control handle shall be placed in neutral position.
Otherwise it will cause the hydraulic system to overheat.
Multi-way valve assembly
1 - Single and double action conversion screw "E"
C
D
Multi-way valve
1-
1+
2-
2+
