12 Technical data
Stability of the dynamic pressure (short-term accuracy)
as per ISO 80601-2-70 in CPAP and APAP mode
- when using the 19 mm hose
4hPa
8hPa
12 hPa
16 hPa
20 hPa
- when using the 15 mm hose, bacteria filter, and
oxygen safety valve
4hPa
8hPa
12 hPa
16 hPa
20 hPa
Δp<0.68 hPa
Δp<0.58 hPa
Δp<0.52 hPa
Δp<0.44 hPa
Δp<0.64 hPa
Δp<1.06 hPa
Δp<1 hPa
Δp<1.08 hPa
Δp<1.02 hPa
Δp<0.96 hPa
Stability of the dynamic pressure (short-term accuracy)
as per ISO 80601-2-70 in modes with 2 pressure levels
at 10 bpm inspiratory
at 15 bpm inspiratory
at 20 bpm inspiratory
at 10 bpm expiratory
at 15 bpm expiratory
at 20 bpm expiratory
Δp = 0.8 hPa
Δp = 1.4 hPa
Δp = 2.4 hPa
Δp = 0.6 hPa
Δp = 0.6 hPa
Δp = 0.6 hPa
Stability of the static pressure (long-term accuracy) as
per ISO 80601-2-70
- when using the 19 mm hose
- when using the 15 mm hose, bacteria filter, and
oxygen safety valve
Δp = 0.15 hPa
Δp = 0.19 hPa
Pressure drop via the oxygen valve
at 90 l/min
at 60 l/min
at 30 l/min
0.5 hPa
0.25 hPa
0 hPa
Recommended maximum additional oxygen 15 l/min
Accuracy of volume measurement at 20 °C
±20 %
Filter and smoothing techniques
• Target volume that can be set:
In the "slow" level, the device checks after every 8 breaths if the target volume has
been reached and changes the pressure by 0.5 hPa. If the pressure reaches a corridor
around the target volume, the device switches to exact regulation.
In the "medium" level, the device checks after every 5 breaths if the target volume
has been reached and changes the pressure by 1.0 hPa. If the pressure reaches a
corridor around the target volume, the device switches to exact regulation.
In the "fast" level, the device checks after every breath if the target volume has been
reached and changes the pressure by 1.5 hPa. If the pressure reaches a corridor
around the target volume, the device switches to exact regulation.
•Alarms:
The "low minute volume" and "low tidal volume" alarms are triggered if at least
three of the last five breaths were below the alarm limit. The alarms are reset
automatically as soon as the corresponding alarm limit is exceeded again with at
least three of the five breaths.
If a target volume is activated, the "low tidal volume" alarm is only triggered once
IPAPmax or PDIFFmax has also been attained.
The "Apnea" alarm is triggered if apnea is identified which is longer than the set
alarm limit. The alarm is reset automatically as soon as the end of the apnea is
identified.
Specification Therapy device
