LS tractor LM3560A User Manual

PARTS
OM 0442MW-A
33
HITCH COMPONENTS
REF.
DESCRIPTION
QTY
PART #
1
Anchor rod
1
670225
2
Anchor lever
1
670224
3
Pin "T" 5/8" x 4" PTD
1
669942
4
Spring pin 1/4" x 1 3/4"
3
1600018
5
Compression spring 0.796"OD x 1 5/8" x 0.060" wire
1
2200025
6
Front support
2
670226
7
Hex bolt M12 x 1.75 x 50mm gr.10.9 PTD
8
0200138
8
Lockwasher 12mm PTD
8
1200019
9
Flat washer 12mm (13mm hole) PTD
8
1400030
10
Anchor bushing PTD
2
671192
11
Front Anchor PTD
1
671193
12
Flat washer 1" (1 1/16" hole) PTD
4
1400029
13
Right tractor bracket
1
670216
14
Left tractor bracket
1
671184
15
Spacer
4
670218
16
Hex nut M12 x 1.75 PTD
2
0900017
17
Hex bolt M14 x 2.00 x 50mm gr.10.9 PTD
2
0200140
18
Left 3 point lifting pivot
1
671191
19
Right 3 point lifting pivot
1
671190
20
Flat washer 14mm (15mm hole) PTD
2
1400024
21
Lockwasher 14mm PTD
2
1200014
22
Hex nut M14 x 2.00 PTD
2
0900055
23
Hex bolt M12 x 1.75 x 70mm PTD
2
0200063
24
Hairpin 4 mm x 80 mm PTD
2
1800002
25
Left lifting arm ass'y
1
671187
- Shoulder bushing 1" lg x 1" ID x 1 1/4"OD
2
4300099
26
Right lifting arm ass'y
1
671185
27
Side bumper bracket
2
671189
28
Linchpin 5/16" PTD
6
1900001
29
Lifting lever PTD
2
670233
30
Cotter pin 3/16" x 2" PTD
2
1500014
31
Flat washer 3/4" (13/16" hole) PTD
6
1400028
32
Pivot spacer PTD
2
670234
33
Compression spring 1 1/2" x 5" x 0.75" wire
2
2200027
34
Nylon insert locknut 3/4"NF PTD
2
1000032
35
Pivot pin 7/8" x 19" PTD
1
670230
36
Flat washer 7/8" (15/16" hole) PTD
2
1400012
37
Chain 3/8 x 5 13/16" PTD
2
2300018
38
Pin 1/2" x 1 3/4" lg PTD
2
665113
39
Circle cotter 1 1/8"OD PTD
2
1900010
40
Carriage bolt 1/2"NC x 1 3/4" lg PTD
4
0300025
41
Flat washer 1/2" (9/16" trou) PTD
4
1400006
42
Lockwasher 1/2" PTD
4
1200006
43
Hex nut 1/2"NC PTD
4
0900006
44
Hex bolt full thread 5/8"NC x 3 1/2" lg PTD
2
665002
45
Jam nut 5/8"NC PTD
6
0900039
46
Crossbar
1
671200
