LS tractor LM3560A User Manual

SPECIFICATIONS
OM 0442MW-A 3
Features and Specifications
60" LAWN MOWER
HOUSING
Cutting width – in (cm)
60 (152)
Construction
Welded drive-over floating deck
Blade quantity
3
Blade length – in (cm)
21 (53) diagonal
Blades thickness - in (mm)
1/4 (6)
Blade overlap - in (cm)
1 5/16 (3)
Weight - lbs (kg)
372 (169)
Housing thickness
10 Ga
Housing depth - in (cm)
4 3/4 (12)
Belt guard thickness
10 Ga
Distance between blade and housing bottom edge
3/4 (2)
Front and side reinforcement thickness
3/8 (1)
Chute material
Reinforced rubber 3/16" (0.5cm) thick
Chute width – in (cm)
12 (30.5)
Gage wheel quantity
4
Gage wheel dimensions
FRONT: 6 1/4" diam. x 3" large
(16cm diam. x 7.6cm large)
REAR: 6" diam. x 2" large
(15cm diam. x 5cm large)
Cutting height
1", 1 5/8", 2 1/4", 2 7/8", 3 1/2", 4 1/8"
(2.5, 4, 5, 7, 9, 10 cm)
MOWER DECK DRIVE
Mower input speed at gearbox
2000 RPM
Gearbox speed increase ratio
Ratio 1 : 1.42
Gearbox output speed
2842 RPM
Gearbox type
Cast iron
Driving pulley
Cast iron MBL67, 6 3/4" (17 cm) outside diam.
Spindle driven pulley
Split pulley 6 1/2" (16.5 cm) outside diam.
Blade tip speed
16 000 fpm
Belt tensioner
Spring loaded
Belt idler dimension
6" diam x 1" large
(15 cm diam. x 2.5 cm large)
Belt type
Single B Kevlar reinforced
Spindle shaft diameter
25mm upper diameter and 30mm lower diameter
Spindle shaft material
1045
Spindle bearing housing material
Ductile iron
Upper spindle bearing type
Single seal 25mm shaft ball bearing
Lower spindle bearing type
Single seal 30mm shaft ball bearing
PTO type
15 splines telescopic member
ANTI-SCALP WHEELS
Quantity of anti-scalp wheels
1 middle front and 1 middle rear
Wheel dimensions
2 1/2" diam x 6" large
(6.5 cm diam. x 15 cm large)
