LSIS SV-iS7 series - Page 40

40
4) Display Item List
(1) Mode Display Items : see “Mode shift”.
(2) Group Display Items : see “Group shift”.
(3) Operation Command/Frequency Command Display Items (Type of Sequence
and number of steps are displayed during auto sequence operation)
(4) Monitor Display Items
No Function Display Description
1
Mode
Display
MON Monitor Mode
PAR
Parameter Mode
U&M
USR & Macro Mode
TRP Trip Mode
CNF Configuration Mode
2
Operating
Command
K Keypad operation command
O
FieldBus communication option operation
command
A Application option operation command
R Built-in 485 operation command
T Terminal block operation command
3
Frequency
Command
K Keypad frequency command
V V1 input frequency command
I I1 input frequency command
P Pulse input frequency command
U
Frequency command during UP operation
(Up-Down operation)
D
Frequency command during DOWN operation
(Up-Down operation)
S
Frequency command during STOP operation
(Up-Down operation)
O FBus Option frequency command
X
V2, I2 frequency command of sub-terminal
block
J Jog frequency command
