No Function Display Description
R Internal 485 frequency command
1~9 A~F Sequential frequency command
4
Multi
Function Key
Setting
JOG Key Used for shift to Keypad JOG mode
Local/Remote Used to select local or remote operation
User Group
Select Key
Used to register parameters as a user group in
the parameter mode or delete parameters in
the user group.
5
Inverter
Operating
Status
STP Motor stopped
FWD Operation in forward
REV Operating in reverse direction
DC DC output
WAN Warning
STL Stalling
SPS Speed Search
OSS Software Over Current controlled
OSH Hardware OverCurrent controlled
TUN Auto Tuning
(5) Status Display Items: see “Operating status monitoring”.
(6) Monitor Mode Display Items: see “Operating status monitoring”.
