Mode Display Description
Monitor mode MON
Displays information on the operating status of the inverter.
Can monitor frequency setting, operating frequency display,
output current and voltage, etc.
Parameter
mode
PAR
Used to set functions necessary for operation. Divided into a
total of 12 groups, each suited to the level of the functional
requirement and objective.
User & Macro
mode
U&M
Facilitates the grouping of the required functions by using
user group and macro group. This is not displayed unless the
user code is not registered nor when the user/macro mode
shifts with the mode key unless the macro is selected.
Trip mode TRP
In case of a failure during operation, the type of failure and
the information on the operating frequency/current/voltage at
the time that the failure occurred are displayed. You can also
monitor the type of the trips which previously occurred. Trip
Mode is however, not displayed when there is no previous
failure history during normal operation.
Configuration
mode
CNF
You can set the user environment for the inverter itself,
provided that it is not directly related to operating functions
such as keypad language selection, monitor mode
environment selection, display type of the option card fitted to
the inverter, parameter initialization and copying.
1) Parameter mode
Mode Display Description
Drive group DRV
Functions necessary for operation including
frequency/acceleration/deceleration time setting and
operation command selection, etc.
Basic group BAS
Sets the basic functions such as the motor parameter
and sequential frequency, etc.
Advanced function
group
ADV
Sets the acceleration/deceleration pattern and
frequency control function, etc.
Control function
group
CON
Sets functions related to sensorless and vector
control.
Input terminal
function group
IN
Sets functions related to the inverter input terminal
block including multi-function digital inputs and analog
inputs.
