44
Output terminal
function group
OUT
Sets the inverter output terminal block functions such
as the relay and analog outputs.
Communication
function group
COM
Sets the functions related to built-in RS-485
communication and any communication option card
where applicable.
Application function
group
APP
Sets functions such as PID control and auto sequence
operation.
Auto Sequence run
group
AUT
This group is displayed if Auto Sequence Group in
APP group is selected and sets the functions
necessary for auto sequence operation.
Application option
group
APO
Sets functions related to the encoder option and PLC
option card, if they are being used.
Protection group PRT
Sets functions related to the motor and inverter
protection.
Motor 2 function
group
(Motor 2)
M2
This group is displayed when Motor #2 is selected
among the multi-function input terminal functions and
sets functions related to Motor #2.
2) User& Macro mode
Group
Displa
y
Description
User group USR
Of the function items of each group of the parameter
mode, the items that need to be monitored or that are
frequently set by the user are grouped and displayed.
They are registered by using the multi-function key of
the keypad.
Macro group MCx
The required inverter load functions can be grouped
and selected at the time of delivery from the factory. If
the user selects a desired type of operation, the
groups displayed in MC1 or MC2 are shown. You can
select them in CNF Mode. For more details, see 8-48
page, 8.1.31 Addition to Macro Group in the detailed
user manual, available from LSIS website.
