2) Possible items for monitoring
Mode
Code
Function
Display
Setting Range Initial Value
CNF 20 Anytime Para 0 Frequency 0 : Frequency
21 Monitor Line-1
1 Speed 0 : Frequency
22 Monitor Line-2
2 Output Current 2 : Output Current
23 Monitor Line-3
3 Output Voltage 3 : Output Voltage
4 Output Power
5 WHour Counter
6 DCLink Voltage
7 DI Status
8 DO Status
9 V1 Monitor[V]
10 V1 Monitor[%]
11 I1 Monitor[mA]
12 I1 Monitor[%]
13 V2 Monitor[V]
14 V2 Monitor[%]
15 I2 Monitor[mA]
16 I2 Monitor[%]
17 PID Output
18 PID ref Value
19 PID Fdb Value
20 Torque
21 Torque Limit
22 Trq Bias Ref
23 Speed Limit
24 Load Speed
25 Temperature
