98
Inverter applied
Cable
mm² AWG
R,S,T U,V,W R,S,T U,V,W
200V
0.75 kW 2.5 2.5 14 14
1.5 kW 2.5 2.5 14 14
2.2 kW 2.5 2.5 14 14
3.7 kW 4 4 12 12
5.5 kW 6 6 10 10
7.5 kW 10 10 8 8
11 kW 16 16 6 6
15 kW 25 22 4 4
18.5 kW 35 30 2 2
22 kW 35 30 2 2
30 kW 70 70 1/0 1/0
37 kW 95 95 2/0 2/0
45 kW 95 95 2/0 2/0
55 kW 120 120 3/0 3/0
75 kW 150 150 4/0 4/0
400V
0.75~1.5kW 2.5 2.5 14 14
2.2 kW 2.5 2.5 14 14
3.7 kW 2.5 2.5 14 14
5.5 kW 4 2.5 12 14
7.5 kW 4 4 12 12
11 kW 6 6 10 10
15 kW 16 10 6 8
18.5 kW 16 10 6 8
22 kW 25 16 4 6
30~37 kW 25 25 4 4
45 kW 70 70 1/0 1/0
55 kW 70 70 1/0 1/0
75 kW 70 70 1/0 1/0
