LSIS SV-iS7 series Manual

99
90 kW 100 100 4/0 4/0
110 kW 100 100 4/0 4/0
132 kW 150 150 300 300
160 kW 200 200 400 400
185 kW 200 200 400 400
220 kW 250 250 500 500
280 kW 325 325 650 650
315 kW 2x200 2x200 2x400 2x400
375 kW 2x250 2x250 2x500 2x500
Signal (Control) Cable Specifications
1) Use STP (shielded twisted-pair) cables for signal wiring.
Terminals
Wire thickness
1)
mm
2
AWG
P1–P7/CM/VR/V1/I2/24 0.33–1.25 16–22
AO1/AO2/CM/Q1/EG 0.33–2.0 14–22
A1/B1/C1/A2/C2/A3/C3/A4/C4/A5/C5 0.33–2.0 14–22
S+,S-,SG 0.75 18
