Page 8-126 LTV
®
1200/1150 Ventilator Service Manual p/n 18603-001, Rev. C
Thermo Conductive Turbine Pad
Thermo conductive pads should be replaced any time they have hardened, and at least at
the 30,000 hour service. The turbine heat sink pad is located between the inside of the
upper weldment and the turbine.
Parts required for replacement: Tools required:
• Thermo Conductive Turbine Pad P/N
10129
• Phillips screwdriver with torque meter
• Grounded anti-static wrist strap
• Mild cleanser
To replace the thermo conductive turbine pad, see instructions for removing and replacing
the turbine manifold on page 8-127.
