LTV 1200 - LTM;LTV Mounting Bracket (Earlier Model LTM)

Page 8-22 LTV
®
1200/1150 Ventilator Service Manual p/n 18603-001, Rev. C
LTM/LTV
®
mounting bracket (earlier model LTM)
Earlier model LTM Graphics Monitors require a two piece mounting assembly as shown
below.
WARNING
Mounting screw use – Internal damage to the ventilator may result if the wrong length
mounting screws are used when installing or removing external accessories.
Accessory mounting screws - Refer to the information supplied with the replacement
screws kit, P/N 11149, to determine the appropriate accessory mounting screws or
accessory replacement screws to use when removing or exchanging external accessories
on an LTV
®
1200/1150 ventilator.
