p/n 18603-001, Rev. C LTV
®
1200/1150 Ventilator Service Manual Page 8-127
Turbine Manifold
Parts required for replacement: Tools required:
Turbine Manifold Assembly P/N 11490
Cable Tie P/N 10466
O
2
Donut Seal P/N 10603
Silicone Gel Lubricant P/N 10123
62
RTV Silicone Adhesive P/N 10122
Replace if damaged:
Thermo Conductive Pad P/N 10129
Sealing Gasket P/N 10175
Damping Grommets (4) P/N 10266
Grounding Clips (4) P/N 10752
Green O
2
Port Cover (O
2
Block) P/N 14446
Phillips screwdriver with torque
meter
Grounded anti-static wrist strap
Small dykes or cutters
Mild cleanser
Cable tie tool
Flow Valve Insertion Tool (Mylar)
P/N 14206
Torque screwdriver
(120 in-oz/o.84 Nm)
When replacing the turbine manifold assembly, it is easiest to remove several components
and replace them together. These will be done in the following order:
Remove the back panel and disconnect the battery
Remove the left soft side
Remove the motor board
Remove the flow valve
Remove the turbine manifold and oxygen blender as a unit
Disconnect the oxygen blender (LTV
®
1200) or O
2
Block (LTV
®
1150) from the turbine
manifold
Connect the new oxygen blender (LTV
®
1200) or O
2
Block (LTV
®
1150) to the turbine
manifold
Replace the oxygen blender (LTV
®
1200) or O
2
Block (LTV
®
1150) and turbine manifold
as a unit
Replace the flow valve
Replace the motor board
Replace the left soft side
Reconnect the battery and replace the back panel
62
In the European Union, Loctite® 8104 may be substituted as an equivalent compound.
