p/n 18603-001, Rev. C LTV
®
1200/1150 Ventilator Service Manual Page 3-1
Chapter 3 - R EAL -T IME T RANSDUCER D ATA
The real-time transducer data allows you to view the real-time activity in the ventilator. The
menu is set up as follows:
RT XDCR DATA
AP xx.xx
c
m
H
2
0
FDb xx.xx
c
m
H
2
0
FDw xx.xx
c
m
H
2
0
FDn xx.xx
c
m
H
2
0
FTw or FTn
xx.xx Lpm
FTb x.xx Lpm
LEAK xx.xx Lpm
FVd xx.xx
c
m
H
2
0
FV xx.xx Lpm
STEP xxxx
FVt xxx.x °F
TS xxxx rpm
O2
4
xx.xx PSIG
BV xx.xx VOLTS
EV xx.xx VOLTS
PPP xx.xx
c
m
H
2
0
RT EXIT
Each item displays real-time activity in the displayed units. For some items, transducer
counts can also be displayed. Pressing Select while a specific transducer is displayed
shows additional data for that transducer.
Display Real-time Data
AP xx.xx
c
m
H
2
0
Airway pressure as measured at the patient wye using the high
side proximal sense line.
FDb xx.xx
c
m
H
2
0
Flow differential pressure as measured at the patient wye using
the bi-directional transducer. Differential pressure is measured
between the high and low side proximal sense lines.
FDw xx.xx
c
m
H
2
0
Flow differential pressure as measured at the patient wye using
the wide scale transducer. Differential pressure is measured
between the high and low side proximal sense lines.
4
Available on the LTV
®
1200 Only.
