Lucent Technologies Lineage
®
2000 50A -48V 364A-3 SR Series Rectifier
2 - 2 Product Description Issue 6 January 1997
Notes:
1. Data specified for nominal input voltages and frequencies
and rate outputs of 55.5 volts and 50 amperes.
2. Data describing regulation, ac ripple, and output noise are
specified at the terminals of a 200 ampere-hour battery
(8-hour rate) with the rectifier operating as specified above
and with the Bellcore-specified 1-volt lead drop between
the rectifier and the battery terminals.
3. For altitudes of 5000 to 13000 feet, derate maximum
temperature by 3.6° F per 1000 feet above 5000 feet. For
altitudes of 1524 to 3962 meters, derate maximum
temperature by 0.656° C per 100 meters above 1524
meters.
Altitude
-200 to 13,000 feet (-61 to 3962
meters) (See Note 3.)
Humidity 10 - 95% non-condensing
Audible Noise
57 dBA measured from 2 feet (0.6
meters) from the rectifier
Electrostatic Discharge IEC 801-2 Level 5
Radiated and Conducted
Emissions
FCC Level A, CISPR Level A
Electromagnetic
Immunity
10V/m over the range of 20 to
2000 mHz
Earthquake Rating Zone 4, upper floors
Safety Agency
Approvals
UL 1950
Table 2-A: 364A3 Electrical Specifications
