Lucent Technologies Lineage

2000 50A -48V 364A-3 SR Series Rectifier

5 - 14 Installation Issue 6 January 1997

Note

If LED’s status is not as specified, refer to Section 7,

Maintenance, for troubleshooting help.

Figure 5-1: Rectifier Shelf Assembly

Remove the Hole Plugs

from the Desired AC Feed

Side of the RSA
