Lucent Technologies Lineage
®
2000 50A -48V 364A-3 SR Series Rectifier
5 - 4 Installation Issue 6 January 1997
14. The rectifier positions should be numbered in the
J85500G-2 plant from right to left and to correspond to the
locations assigned by the controller software. Apply the
appropriate rectifier labels (Item 7) to the face of the
rectifier front cover.
Wiring AC Into
a -48V RSA
Installation procedures must be performed in the sequence given
when wiring ac into an RSA. Please review Section 4, Safety,
before proceeding.
RSA Setup Refer to Figure 5-1 and proceed as follows:
1. Determine from which side of the RSA the individual ac
line feeds will enter the RSA.
2. Remove all RSA rectifier slot covers.
3. Remove the hole plugs from the desired ac feed side of the
RSA.
Installation of
AC Power to the
RSA
1. Disconnect ac power from distribution box/panel to be
used to supply power to the RSA rectifiers.
2. Install fuse holders or circuit breaker for each feed line in
distribution box/panel. Remove fuses or set circuit breaker
in OFF position.
3. Route the ac input line feeds in BX (armored) cable,
flexible cable, or 1/2 inch conduit, as required by local
wiring code, to the selected RSA side.
Note
In the J85500G-2 plant, ac line feeds will enter only from the
right.
Note
If the RSA is not fully wired, wire the slot furthest from the
side where the ac lines enter.This will allow operating
rectifiers to remain on line while an unused rectifier RSA slot
is later filled.
To Next Page
