Lucent Technologies Lineage
®
2000 50A -48V 364A-3 SR Series Rectifier
Issue 6 January 1997 Product Description 2 - 11
DC Distribution: provides overcurrent protection, connection
points for the using equipment, and bus bars used to interconnect
the rectifiers, batteries, plant shunt, and dc distribution.
Converters: transform -48-volt source voltages into regulated,
low noise 24-volt dc power sources for use with
telecommunications loads.
Figure 2-1: Block Diagram of a Typical Battery Plant
ELECTRIC
UTILITY
(AC POWER)
ENGINE
ALTERNATOR
DC-DC
CONVERTER
DC-DC
CONVERTER
AC
LOADS
DISTRIBUTION
FACILITIES
TYPICAL EQUIPMENT FRAME
DC POWER PLANT
OUTPUTVOLTAGES
DC-AC
INVERTER
FUEL
STORAGE
TRANSFER
SWITCH
RECTIFIER
CONTROL
AND
MONITOR
CONTROLLER
RECTIFIER
DCPOWER PLANT
AC INPUT
BATTERY
