3 - 14 Engineering and Ordering Issue 6 January 1997
Table 3-F: Additional Items Needed to Field Install RSA
DC Feeder Cable
Ordering Code Description
402700470 1/0 Cable
996607925
Term Lug, 2-hole
3/8, T&B 54210
996587101
Term Lug, 2-hole
5/16, T&B 54216
901062737
HS Tubing, WP91767, L6
3/4-inch.
DC Feeder Cable
Mounting Hardware
Size Ordering Code Description
5/16
814251880 Washer
802986273 Lock Washer
841064769 Hex Nut
3/8
801273129 Hex Screw
814251898 Washer
801829607 Lock Washer
841064777 Hex Nut
Alarm and Control Lead Ribbon
Cable
Ordering Code Description
846666204 Ribbon Cable (24-inch.)
846666212 Ribbon Cable (36-inch.)
846666220 Ribbon Cable (48-inch.)
846666238 Ribbon Cable (60-inch.)
846666253 Ribbon Cable (72-inch.)
Mounting Brackets
and Screws
Frame
Width
Ordering Code Description
23.5 inches 846579647 Bracket, Right and Left
21.5 inches
846646271 Bracket, Right
846646321 Bracket, Left
All 901078717
12-24 x 5/8 Hex Screw (4
per Bracket)
