Lucent Technologies Lineage
®
2000 50A -48V 364A-3 SR Series Rectifier
Issue 6 January 1997 Installation 5 - 15
Figure 5-2: RSA Wiring Instructions
Left
AC
Feed
Right
AC
Feed
ACEG ACEG ACEG
AC
Feed for
J85500G
Recommended AC Fitting
Torque of
18 In-Lbs
Crimp Tool (T&B)
No. WT130C
or No. WT3155A
Cable Type
Conduit
Armored
Flexible
8130
3132
2251
8131
–
–
Fitting (T&B)
1/2" 3/4"
