Lucent Technologies Lineage
®
2000 50A -48V 364A-3 SR Series Rectifier
Issue 6 January 1997 Operating Controls and Displays 6 - 3
EQ (14) This yellow LED provides a visible indication that the rectifier
is in equalize mode.
CB OFF (15) This yellow LED provides a visible indication that the output
breaker is open.
DC OUTPUT
Circuit Breaker
(16)
Used to disconnect the rectifier from the output bus for test
purposes. It also protects the plant from rectifier malfunction and
overcurrent conditions. When the circuit breaker is in the OFF
position, the yellow LED CB OFF indicator is lit and an alarm is
sent to the controller.
DIP Switch (17) Used to set rectifier internal selective high voltage shut down
level (Switches 1-4), enable/disable the load share function
(Switch 5), and to set back-up high-voltage shutdown level
(Switches 6 and 7).
Interface
Connector (18)
Thirty-four (34) pin keyed connector provides interface between
rectifier and controller via RSA ribbon cable. See Table 3-A and
list of descriptions (Section 3, “Rectifier Control Signals”) for
details of the signals available at this connector.
Mounting Screw
(19)
Hex screw used to secure rectifier to the RSA.
Test Connector
(20)
A ten pin keyed factory test connector.
Note
The screw is accessible only with DC OUTPUT circuit
breaker in the OFF position.
Note
This is a factory test connector and is not used during field
maintenance. Improper use of this connector can result in
rectifier damage.
