Lucent Technologies Lineage
®
2000 50A -48V 364A-3 SR Series Rectifier
Issue 6 January 1997 Introduction 1 - 1
1 Introduction
General
Information
This product manual describes Lucent Technologies’ Lineage
®
2000 364A3 50-ampere, -48-volt SR series rectifier (Figure 1-1)
and the associated rectifier shelf assemblies, J85702B-2 and
J85702F-1 (Figure 1-2). The 364A3 rectifier replaces all
364A-type rectifiers described in previous issues of this product
manual. These rectifiers are backward and forward compatible
and may be interchanged at will in any system. Although the
apparatus codes and comcodes are different, the ordering
procedures are identical for all -48-volt SR series rectifiers.
Lucent Technologies has designed the 364A3 rectifier
specifically for applications where small size, low weight, and
ease of installation and maintenance are critical. UL recognized,
the 364A3 rectifier can be operated with or without batteries,
providing maximum applications flexibility. The rectifier is
plugged into the Rectifier Shelf Assembly (RSA) and all
interconnections between the controller, rectifier, and
distribution are completed.
A complete technical description of the product is covered in this
manual as well as detailed information on engineering,
installation, operation, and maintenance.
Technical
Support
Technical support for Lucent Technologies equipment is
available to customers around the world.
USA, Canada,
Puerto Rico, and
the US Virgin
Islands
On a post-sale basis, during the Product Warranty period, our
Technical Support telephone number 1-800-CAL RTAC
(1-800-225-7822) provides coverage during normal business
hours. Product Specialists are available to answer your technical
