Lucent Technologies Lineage
®
2000 50A -48V 364A-3 SR Series Rectifier
Issue 6 January 1997 List of Tables - 1
List of Tables
Table 2-A: 364A3 Electrical Specifications 2 - 1
Table 2-B: 364A3 Physical Specifications 2 - 3
Table 2-C: Lightning and Switching Surge Protection 2 - 9
Table 3-A: AC Input 3 - 2
Table 3-B: Rectifier Control Signals 3 - 5
Table 3-C: Rectifier Ordering Information 3 - 12
Table 3-D: J85702B-2 RSA Ordering Information 3 - 12
Table 3-E: J85702F-1 RSA Ordering Information 3 - 13
Table 3-F: Additional Items Needed to Field Install RSA 3 - 14
Table 3-G: Recommended Spare Part 3 - 15
Table 5-B: 364A3 Rectifier Dip Switch (701) Settings 5 - 10
