Lucent Technologies Lineage
®
2000 50A -48V 364A-3 SR Series Rectifier
3 - 12 Engineering and Ordering Issue 6 January 1997
364A3 Rectifier
Rectifier Shelf
Assemblies
Notes:
1. Lists 3 and 4 provide one set of three individual ac line
feeds on the left side of the rectifier shelf assembly and
two sets of three individual ac line feeds on the right. The
input hole diameter is .875 inches sized for .50 inches trade
size conduit. Recommended conduit fittings are as follows:
Table 3-C: Rectifier Ordering Information
Apparatus Code Comcode
364A3 107310187
Table 3-D: J85702B-2 RSA Ordering Information
List Description
3
Equipment required to mount a
maximum of three 48-volt, 50-ampere
SR series rectifiers. The dc output from
the shelf is rear cabled. (See Notes 1, 2,
and 4.)
4
Same as List 3 except DC output is for
rear bus plants of the J85500G type.
(See Notes 1, 2, and 4.)
5
Same as List 3 except controller
circuitry is configured for use with
J85501F-1 Galaxy Controller.
6
Equipment required to mount a
maximum of three 48-volt, 50-ampere
SR series rectifiers. (For use with
J85500L-1 Battery Plant only.)
7
Equipment required to provide one
48-volt, 50-ampere rectifier. (See Note
3 and Table 3-C.)
PM
Optional stand-alone list to provide
product manual, shelf schematic, wiring
T-drawing, and shelf J-drawing.
Cable Type T&B Comcode
Armored or
BX
3132 997087960
