Lucent Technologies Lineage
®
2000 50A -48V 364A-3 SR Series Rectifier
3 - 6 Engineering and Ordering Issue 6 January 1997
AR If a rectifier restarts for any reason it will issue a signal to all
other rectifiers to restart.
ACF AC Fail is a contact closure between ACF and RTN (pin 16)
indicating to the controller that the rectifier ac source voltage has
fallen below approximately 170 vrms or the rectifier input fuses
have operated.
BAT The -48 volt dc plant voltage is required on pin 14 to power the
CH, EQ, HV, and OTR alarm circuits in the rectifier. In ECS
battery plants, the -48-volt source is protected by a 1-1/3 ampere
fuse located on the LVD/R circuit board.
CH Controller Handshake is a contact closure between CH and RTN
(pin 16) originating in the controller. This connection disables
the rectifier's internal high voltage shutdown circuits and allows
the system to rely on the controller's high voltage shutdown
circuits instead.
EQ Equalize is a contact closure between EQ and RTN (pin 16)
originating in the controller, which forces the rectifier into
equalize mode.
Control Signal Abbreviation Pin Number
Regulation REG-2 25
High Voltage HV 26
Regulation REG-1 27
Controller Handshake CH 28
Regulation REG+1 29
Restore Return RSR 30
Regulation REG+2 31
Restore RS 32
Regulation REG+3 33
Table 3-B: Rectifier Control Signals
To Next Page
