Lucent Technologies Lineage
®
2000 50A -48V 364A-3 SR Series Rectifier
Issue 6 January 1997 Engineering and Ordering 3 - 13
One 1.125 inch indented hole diameter is also provided for
each set of three feeds on the right side for .75 inches trade
size conduit. Recommended conduit fitting is No. 8131
(T&B).
2. A cable kit intended for the L3 shelf in a J85500G
supplemental bay consists of 2 cables, each 10 feet long,
with a 2-hole 5/16 (T&B) terminal lug attached at one end
and loose piece kit of mounting hardware and 2-hole 3/8
(T&B) terminal lugs for the exposed end. The kit is
ordered with comcode 846666311.
3. Rectifiers ordered per List 7 are shipped packaged
individually in a container approximately 18 x 21 x 13
inches, weighing approximately 30 pounds.
4. If the J-drawing is used to order a List 3 rectifier shelf for
field upgrade, refer to Table 3-F for additional items
required.
Note:
1. The J85702F-1 List 1 RSA adds an off-line equalize
feature to the J85500L-1 battery plant. If this feature is
upgraded in the field, this RSA is included in J85500L-1
Lists G and H, in addition to all other required equipment
and wiring. This RSA should not be ordered separately.
Flexible 2251 401573951
Rigid
Conduit
8130 402144174
Table 3-E: J85702F-1 RSA Ordering Information
List Description
1
Equipment required to mount a
maximum of three 48-volt, 50-ampere
SR series rectifiers. (For use with
J85500L-1 List G only, maximum one
per plant.) See Note 1.
Cable Type T&B Comcode
To Next Page
