Lucent Technologies Lineage
®
2000 50A -48V 364A-3 SR Series Rectifier
Issue 6 January 1997 Product Description 2 - 1
2 Product Description
Electrical
Specifications
Table 2-A: 364A3 Electrical Specifications
Nominal Output
Voltage
-48 volts dc
Operating Voltage
Range
48-58 volts dc
Output Current 0-50 amperes
Input Voltage 208/220/240 volts ac, single phase
Input Voltage Range 180-264 volts ac
Input Frequency Range 47-63 Hz
Input Current
16.5 amperes @ 208 volts ac
14 amperes @ 240 volts ac
Efficiency 86% typical
Power Factor 0.99 typical
Regulation +0.5%
AC Ripple 250 millivolts peak to peak
Output Noise
22 dBrnc with battery
26 dBrnc without battery
Load Share Accuracy 10 amperes
Heat Dissipation 1540 BTU/hour
Temperature 32° F to 122° F (0° C to 50° C)
