Lutech LT-300 SD - Pre-Assembly Check List; Vertical Stand Parts List; Swing Arm Stand Parts List; Colposcope with Vertical Stand Assembly

Page 14 of 60
components:
LT-300 SD Digital Video Colposcope with Vertical Stand
LT-300 SD Colposcope Camera
1
Remote (no battery required)
1
Power Box SD (Includes box, 2 attachment rings, 4 screws and allen wrench)
1 set
Power Adapter(15V)
1
HDMI Cable (approx. 9.8 feet (3M))
1
USB3.0 Cable (approx. 6.5 feet (2M))
1
Vertical Stand (Includes: Camera Base Mount, Wheel Base, 4 Casters with locks
and pre-threaded SD Main Cable)
1
3-Pedal Foot Switch
1
USB drive loaded with the Lutech Viewer
1
LT-300 HD Digital Video Colposcope with Vertical Stand
LT-300 HD Colposcope Camera
1
Remote (no battery required)
1
Power Box HD (Includes box, 2 attachment rings, 4 screws and allen wrench)
1 set
Power Adapter(15V)
1
HDMI Cable (approx. 9.8 feet (3M))
1
USB3.0 Cable (approx. 6.5 feet (2M))
1
Vertical Stand (Includes: Camera Base Mount, Wheel Base, 4 Casters with locks
and pre-threaded HD Main Cable)
1
3-Pedal Foot Switch
1
USB drive loaded with the Lutech Viewer
1
NOTE: For replacement cables or other accessories, please contact your distributor or Lutech
representative.
2.3 Pre-Assembly Check List
Ensure all parts are present before assembly.
2.3.1 Vertical Stand Parts List
The colposcope with vertical stand configuration will come with the following parts:
• Colposcope camera
• Camera base mount with camera base plate attached
• Vertical tube with the power box attached and the main cable pre-threaded
• Anti-roll wheel base with 4 casters with locking mechanisms
• Wheel base screw set, including: 1 screw, 1 locking washer, 1 regular washer, 1 allen wrench
2.3.2 Swing Arm Stand Parts List
The swing arm stand is an optional accessory for the colposcope. It will come with the following parts:
• Colposcope camera
• Camera base mount with camera base plate attached
• 2 swing arm sections with wire management caps, power box attached and the main cable pre-threaded
• Anti-roll wheel base with 4 casters with locking mechanisms
• Wheel base screw set, including: 1 screw, 1 locking washer, 1 regular washer, 1 allen wrench
2.4 Colposcope with Vertical Stand Assembly
To assemble the colposcope on the vertical stand, follow the steps below.
