2. Installation
2.1 Insert the batteries
Mounting steps:
1. Unscrew the battery compartment lid 20
2. Remove batteries from styrofoam buffer of packaging
3. Insert batteries, checking for correct polarity 19
4. Screw on the battery compartment lid 20
2.2 Turning the operating unit
The operating unit can be turned to the required position in 90°-steps.
Mounting steps:
1. Remove cap
2. Release screws
3. Carefully lift the operating unit, paying attention to cable length!
4. Turn the operating unit to the required position
5. Mount the operating unit
6. Tighten the screws
7. Mount the cap
