GB
56
2.3.1 Connecting the basic version Ex-RM1m B 230 V
The electrical connection between the mains, the pump and solenoid
valve is made in the connecting compartment on the underside of the
relay module.
The relay module Ex-RM1m must be dismantled in accordance with
steps 1-4 of chapter E 2.2.1 when the flow meter system is mounted.
The electrical connection is made in accordance with the following
circuit diagram:
Refer to chapter E 1.1 (Technical data) when making electrical connections
E. Relay module Ex-RM1m
