64
GB
Spare parts list
Accessories for Modular Flow Meter System
Order No. Description Qty.
0211-225 PE transformer cpl. 1
0211-235 impulse adapter 1/4" NPT cpl. 1
0211-236 impulse adapter 3/8" NPT cpl. 1
0211-237 impulse adapter 1/2" NPT cpl. 1
0211-238 impulse adapter 3/4" NPT cpl. 1
0211-239 impulse adapter 1" NPT cpl. 1
0211-269 grounding plate 1-fold 1
0211-374 cover for relay 1
0211-394 screwed cable gland cpl. 1
0212-010 intermediate plate consisting of: 0301-248, 0301-249, 1
0301-251, 0373-003, 3373-004
0300-065 screw 2
0301-039 phillips screw 2
0301-102 ejot-PT-screw 2
0301-126 hexagon nut 2
0301-217 tapping screw 12
0301-222 ejot-PT-screw (for relay module RM1) 4
0301-243 ejot-PT-screw (for relay module Ex-RM1m and RM3) 4
0301-248 ejot-PT-screw (for types ST, SL, LM, UN) 4
0301-249 phillips screw (for type VA I) 4
0301-251 washer 4
0302-150 quick change screw 3
0302-151 hose connector 1
0303-153 plastic hose 3
0314-180 o-ring NBR 5
0314-761 o-ring Perbunan 2
0333-335 locking screw 2
0335-212 finewire fuse 6.3A time-lag (for relay module 120V) 1
0335-213 finewire fuse 4A time-lag (for relay module 230V) 1
0335-214 finewire fuse 0.1A semi time-lag (for relay module RM1) 1
(for relay module RM3) 1
0335-215 finewire fuse 0.5A semi time-lag (for relay module RM1) 1
(for relay module RM3) 2
0335-247 fuse Ex, 4A 1
0335-248 fuse Ex, 500 mA 1
0335-254 relay 1
0336-060 connecting cable relay module 4
0336-061 socket 3
0336-062 plug 1
0336-093 flange box cpl. 1
0336-095 plug 1
0336-096 angle coupling 1
0336-099 coupling 1
0336-106 coupling plug 4
0336-162 power cable relay module Ex-RM1m consisting of: 0336-536 1
0336-536 explosion proof plug 3-pole 1
0363-053 protection foil 1
0373-003 cap 4
0373-008 protection cap for socket 3
0373-009 protection cap for plug 1
