GB
29
3.2.8 Cycle counter
The cycle counter registers the number of filling cycles with the same volume filled. This means that the user
does not have to count the cycles, e.g. when 100 containers have to be filled with the same volume. The cycle
counter starts at zero again when a new filling volume is entered. Interrupted filling processes are not counted.
Changing the SLOW quantity has no effect on the cycle counter.
Operation Display
+ The cycle counter is displayed as long as the key is depressed. It cannot be displayed while filling is
in process.
3.2.9 Filling with step-by-step interruption (SLOW mode)
In the automatic mode, it is possible to carry out the filling process using two different flow volumes. This is
particularly useful for fast, precise filling of large quantities, or when transporting a foaming medium.
Two solenoid valves arranged in parallel are required for this process. The valves are closed at different times, so
reducing pressure surges in the system, and helping to avoid overflowing when transporting foam-forming media.
A throttle element, such as a ball valve in line with the valve disconnected last, to regulate the flow volume is
beneficial. The reduced flow speed volume is entered using the SLOW function.
3.2.9.1 Entering/deleting the SLOW volume
Operation Display
Filling volume flashes
Actual SLOW volume flashes
continued on next page
