1.1 Technical data

Type RM1 230 V RM1 120 V RM3 400/230 V NG1 230 V

Voltage 220-240 V 110-125 V 230/400 V 220-240 V

Frequency 50 – 60 Hz

Switching outputs 2 switching outputs (potentially bound) –

Pump switching current 4 A, cosj > 0.7 8.5 A, cosϕ > 0.7 16 A, cosϕ > 0.7 –

Solenoid valve switching current 0.5 A –

Type of protection IP 44

Explosion protection class II 2G [EEx ib] IIC – – –

Connections round connector

Weight 440 g 430 g 634 g 290 g

Order No. 0212-020 0212-030 0212-060 0212-090

1.2 Application in explosion hazard areas

Danger!

Danger of explosion!

Combustion hazard. Blast wave: Flying parts can cause death.

The relay module RM1, the mains unit NG1 and the connecting cables are not suitable for use in explosion

hazard areas!

If the relay module itself is not located in an explosion hazard area the relay module RM1 230 V may

supply the power and signals to the operating unit in zone 1.

For this application the relay module must be used with an ambient temperature of -20 up to +40°C. This

temperature range is also applied to the measured liquid when the relay module is mounted on the basic

flow meter.

D. Relay module RM1/RM3 and mains unit NG1
