1.2.1 Electrical data
Input: U = 220 - 240 V ~
(ST3) I
max
=8 A
cos ϕ > 0.7
P
max
= 1760-1920 W
Outputs:
Output 1 (Pump): U = 220 - 240 V ~
(ST4 and ST5) I
max
=4 A
cos ϕ > 0.7
P
max
= 880 - 960 W
Output 2 (Valve): U = 220 - 240 V ~
(ST4 and ST5) I
max
= 0.5 A
cos ϕ > 0.7
P
max
= 77 - 84 W
Output intrinsic safety U = 6.6 V =
(ST1 or ST2) I = 165 mA
P = 272 mW
Max. admissible outer
values for: L (mH) C (mF)
21
1 1.6
0.5 2.2
0.2 3
0.1 3.8
D. Relay module RM1/RM3 and mains unit NG1
