2.2 Connection for automatic mode

A number of ready-configured cables are available for connecting up external units:

À Power supply cable relay module RM1/mains unit NG1, 5 m long (Order No. 0211-155)

Á Connecting cable main valve, 5 m long (Order No. 0211-150)

For actuation of a solenoid valve via the relay module RM1or RM3.

Â Connecting cable SLOW-valve, 5 m long (Order No. 0211-151)

Using this cable, a second solenoid valve can be actuated in conjunction with the cable set motor/SLOW,

3-way.

Ã Connecting cable motor/SLOW 1-way, 0.5 m long (Order No. 0211-153)

To actuate a pump motor or second solenoid valve via the relay module RM1.

Ä Connecting cable motor/SLOW 3-way, 0.5 m long (Order No. 0211-154)

This cable is required for connection of 3 external appliances such as motor and two solenoid valves.

Å Power supply cable RM3 230 V, 5 m long (Order No. 0211-387)

For A.C. power supply of the relay module RM3.

Æ Connecting cable motor 230 V, 0.5 m long (Order No. 0211-385)

For actuation of an A.C. driven pump motor via the relay module RM3.

Ç Power supply cable RM3 400 V, 5 m long (Order No. 0211-388)

For 3-phase current power supply of the relay module RM3.

È Connecting cable motor 400 V, 0.5 m long (Order No. 0211-386)

For actuation of a 3-phase current driven pump motor via the relay module RM3

l Extension cable, 5 m long (Order No. 0211-152) (without illustration.)

For extension of the connecting cables À,Á,Ã,Ä.

D. Relay module RM1/RM3 and mains unit NG1
