145
User Guide
© 2014 Luxul. All Rights Reserved.
Other trademarks and registered trademarks are the property of their respective owners
Choose the menu QoS>>DiffServ>>CoS/TC Queue Mapping to load the
following page.
Figure 9-8 CoS/TC Queue Mapping
The following entries are displayed on this screen:
CoS/TC Queue Mapping
Tag-ID/CoS-ID:
Indicates the precedence level defi ned by IEEE 802.1P and the CoS ID.
Queue TC-ID:
Indicates the priority level of the Egress Queue the packets with a Tag or
CoS-ID are mapped to. The priority levels of the Egress Queue are labeled
TC0, TC1, TC2 and TC3.
CoS/TC Queue Mapping settings will be restored to defaults if the Switch is restarted
and you have not selected Save Confi g from the main menu and saved your running
confi guration to non-volatile memory.
