144
XMS-1024P
a: 14203 Minuteman Drive, Suite 201, Draper, UT 84020-1685 | luxul.com | 801-822-5450
LUX-UG-XMS-1024P Vers: 081314
CONFIGURATION PROCEDURE:
Step Operation Description
1
Configure the mapping
relationship between DSCP
Priority and 802.1P Priority
On QoS>>DiffServ>>DSCP Priority page Enable
DSCP Priority and configure the Mapping relationship
between the DSCP Priority and 802.1P Priority. (All
values have a default mapping that can be changed
if needed.)
1
Configure the mapping
relationship between the
802.1P Priority and TC
On QoS>>DiffServ>>CoS/TC Queue Mapping page
configure the mapping relationship between the 802.1P
Priority and TC. (All values have a default mapping that
can be changed if needed.)
2
Select a Priority Schedule
Mode
On QoS>>DiffServ>>Schedule Mode page select a
Priority Schedule Mode.
9.1.3 802.1P/CoS mapping
On this page you can configure the mapping relationship between the 802.1P Priority
Tag-ID/CoS-ID and the TC-ID.
802.1P gives the PRI field in 802.1Q Tags a recommended definition ranging from 0-7.
This Tag is used to divide packet streams into 8 priorities. 802.1P Priority is enabled by
default so any packets with an 802.1Q Tag are Mapped to different priority levels based
on 802.1P Priority Mode. Any Untagged packets are Mapped based on Port Priority
Mode. Any packets with the same value in the 802.1P Priority Tag or Port CoS value will
be mapped to the same TC-ID.
