Luxul XMS-1024P User Manual

166
XMS-1024P
a: 14203 Minuteman Drive, Suite 201, Draper, UT 84020-1685 | luxul.com | 801-822-5450
LUX-UG-XMS-1024P Vers: 081314
Choose the menu ACL>>ACL Time-Range>>ACL Time-Range Table to load the
following page:
Figure 11-1 ACL Time-Range Table
The following entries are displayed on this screen:
ACL Time-Range Table
Select:
Select the desired entry to Delete the corresponding Time-Range.
Index:
Displays the Index of the Time-Range.
Time-Range Name:
Displays the Name of the Time-Range.
Slice:
Displays the Time-Slice of the Time-Range.
Mode:
Displays the Mode of the Time-Range.
Confi guration:
Click Edit to modify this Time-Range and click Detail to display the
information of this Time-Range.
CAUTION: ACL Time-Range Table settings will be restored to defaults if
the Switch is restarted and you have not selected Save Confi g
from the main menu and saved your running confi guration to
non-volatile memory.
11.1.2 ACL Time-Range
On this page you can create Time-Ranges.
Choose the menu ACL>>ACL Time-Range>>ACL Time-Range to load the
following page.
