41
User Guide
© 2014 Luxul. All Rights Reserved.
Other trademarks and registered trademarks are the property of their respective owners
The following entries are displayed on this screen.
Mirror Group List
Group:
The Mirror Group number.
Mirroring:
The Mirroring Port number (destination Port).
Mode:
Indicates the traffi c mirroring options of Ingress or Egress sources.
Mirrored Port:
Displays the Mirrored Ports and whether they are mirroring Ingress, Egress
or Both.
Operation:
Click Edit to confi gure the mirror group.
Edit to displays the following page.
Figure 5-3 Mirroring Port
