8
XMS-1024P
a: 14203 Minuteman Drive, Suite 201, Draper, UT 84020-1685 | luxul.com | 801-822-5450
LUX-UG-XMS-1024P Vers: 081314
Chapter Introduction
Chapter 8 Multicast
This chapter will show how to configure the Multicast
functions of the Switch.
IGMP Snooping:
Configure global parameters of IGMP
Snooping, Port properties, VLAN, and Multicast VLAN.
Multicast IP:
Configure Multicast IP table.
Multicast Filter:
Configure Multicast Filter to restrict
users ordering Multicast programs.
Packet Statistics:
View the Multicast traffic statistics on
each Port of the Switch.
Chapter 9 QoS
This chapter will show how to configure QoS to provide
the desired quality of service for various Network
applications and requirements
DiffServ:
Configure priorities, Port priority, 802.1P
Priority and DSCP priority.
Bandwidth Control:
Rate Limit feature to control the
traffic rate on each Port; Storm Control feature to filter
Broadcast, Multicast and UL frames in the Network.
Voice VLAN:
Voice VLAN to transmit Voice Data stream
within the specified VLAN to ensure the transmission
priority of Voice Data stream and Voice quality.
Chapter 10 PoE
This chapter will show how to configure the PoE for the
Switch to supply power for PoE capable devices.
PoE Config:
PoE global functionality.
PoE Time-Range:
Time window(s) for PoE Port to
supply power.
Chapter 11 ACL
This chapter will show how to configure ACL Rules and
Policies to filter packets in order to prevent malicious
packets from harming the Network.
Time-Range:
The effective time for ACL Rules.
ACL Config:
ACL Rules.
Policy Config:
Policy operational parameters.
Policy Binding:
Bind the policy to a Port or VLAN.
