LX 10k
LX Joy
Document name: LX 10KUM
Document revision: R1
The BOX button will mimic the pressing of the BOX button on the LX 10k.
The ’X’ button will mimic the pressing of the left push-rotary knob on the LX 10k.
The PTT button is connected to the Radio and does not influence the LX 10k.
NOTE
The LX 10k is not compatible with the legacy LX Remote Stick.
NOTE
The BOX push button and the LED are without function when in use with the LX
10k. The LED is reserved for use with a Zeus, while the BOX can be used either by
an LX 10k or with a Zeus.
NOTE
Newer LX Joys feature a Vibra motor, giving the pilot not only audio and visual
warnings, but vibration warnings as well.
NOTE
There are different HW iterations of the current LX Joy. LX 10k is compatible with
all of them, although older and Zeus-type LX Joys will have different button icons.
Nevertheless, the functions of those buttons will stay the same as described in
this section.
NOTE
New hardware versions of the LX Joy utilize SC switch communication over the
CAN cable, and thus lack the two wires going from the Joy to the LX 10k’s Inputs
interface. Older hardware versions of the LX 10k will require the SC command
button be connected to the Inputs interface. For additional info, check the Inputs
section
.
Device manual Public 97
