LX 10k
Device setup
Document name: LX 10KUM
Document revision: R1
5.1.3 Task
The Task setup sub-menu is used for setting up the default sectors for turnpoints to be used,
when a new task is created. The sub-menu holds the following settings:
• Default start - sets the default starting sector parameters
• Default point - sets the default turnpoint sector parameters
• Default finish - sets the default finish sector parameters
5.1.4 Indicators
The Indicators setup sub-menu holds the setup parameters for indicators on
Vario Indicator Unit. Two different sets of indicators can be set for each flight mode.
The two flight modes - circling and straight flight are denoted as Vario (circling) and SC (straight
flight, ’Speed Command’). Different indicators can be assigned both to the needle as well as
to numerical indicators. Pressing the SC switch will change between the two sets of indicators.
Depending on the type of the Vario Indicator Unit, you can have either the option of 4 NavBoxes
(for the digital unit) or 2 NavBoxes (for the analog unit). Furthermore, the Digital unit can be set
to showing 2 larger NavBoxes instear of 4 smaller ones, if the ’4 NavBox items’ is checked. The
following settings are available here:
• Vario needle
• 4 NavBox items
• Vario NavBox 1
• Vario NavBox 2
• Vario NavBox 3
• Vario NavBox 4
• SC needle
• SC NavBox 1
• SC NavBox 2
• SC NavBox 3
• SC NavBox 4
If the system has the digital vario indicator unit, the pilot can also choose between two and four
numerical indicators on the main page, offering a choice between more info and better legibility.
The following digital needle indicators are available:
• Vario - shows the current compensated vertical speed (vario value)
• SC - shows the current SC (Speed Command) value - same as the green arc, as described
in the Vario Indicator Unit sub-section
• Netto - described below
• Relative - described below
• G-force - the current G-force, as described in the G-force page sub-section
Device manual Public 56
