LX 10k
Advanced operation
Document name: LX 10KUM
Document revision: R1
Advanced operation
Primary pages overview
This section will cover the complete specter of operations possible on LX 10k’s primary pages.
There are 12 primary pages on the LX 10k. You can scroll between these pages by using the
right push-rotary knob (PAGES). The pages are listed as follows:
1. Turnpoint navigation page
2. Airport navigation page
3. Task navigation page
4. Nearest landable navigation page
5. Thermal assistant page
6. Flarm radar page
7. AHRS page
8. G-force page
9. Info page
10. Logbook/Flight statistics page
11. Airspace page
12. Setup page
4.1 Navigation pages
The LX 10k offers 4 separate navigation pages, giving the pilot simultaneous navigation to a
turnpoint, airport, over a task and to the nearest landable point.
The basic layout of each navigation page is the same. In the top of the page, we can see the
header. Below the header, we can see the moving map, the wind indicator on the left and the
final glide indicator on the right. Above the final glide indicator, a zoom scale is positioned and
in the bottom of the page, the NavBox line is positioned.
Pressing the left push-rotary knob will show additional info for the point we’re currently
navigating to on the tunpoint, airport and nearest landable page and open additional task
options on the task navigation page. Rotating the left push-rotary will change the zoom level.
Pressing the left push button will initiate NavBox line commands. A short press will change
between 3 different NavBox lines, and a long press will initiate the ’Select NavBox’ dialog.
Device manual Public 19
