M7 OMPHOBBY - ESC Plate and Flight Controller Mount

Countersunk
Screw M2.5x5 (×6)
(7-155)
Mounting Crossmember
45mm (×3)
(7-019)
ESC Mount (×1)
(7-005)
Hex Screw
M3x6 (×6)
(7-126)
Hex Screw
M3x8 (×4)
(7-127)
Tail Boom Clamp
Front (×1) (keyed)
(7-035)
Tail Boom Clamp Rear
(×1) (round hole)
(7-036)
POM Boom
Clamp Insert (×1)
(7-095)
Countersunk Screw
M2.5x5 (×4)
(7-155)
Countersunk Screw
M3x12 (×4)
(7-156)
Inertial Mass
Damper (×1)
(7-059)
Damper Rubber (×4)
(7-044)
Flight Controller
Mount (×1)
(7-006)
01 ESC Plate Assembly
02 Installation of the ESC Plate
03 Flight Controller Mount and Boom Clamps
Upper Frame Assembly
Page
The ESC Plate can accommodate
a variety of ESCs for direct mounting
with M3 hex screws and nyloc nuts,
such as Sunnysky, Scorpion,
Hobbywing, YGE, Kontronik.
The inertial mass damper only needs
to be installed with inertial measurement
units (gyroscopes/accelerometers) of the
ICM-20XXX series. MPU-6000, Bosch BMI
series Gyroscopes, as well as ICM-4XXXX
series IMUs do not require the mass
damper to be installed.
Damper Rubber
Bushing (×4)
(7-231)
Glue
Glue
Glue
Glue
Glue
BAG 5
