MacDon A30-D - SELF-PROPELLED COMPONENTS

UNLOADING AND ASSEMBLY
169001 Revision E
20
IMPORTANT
Adjust safety chain length to remove all
slack - except what is needed for turns.
h. Raise jack (D), pull pin (J), and move jack to
storage position on side of APT.
i. Secure jack with pin (J).
j. Proceed to STEP 13. ATTACH HYDRAULICS
AND ELECTRICAL.
J
D
J
