5-122 Magellan

2200VS/2200VS and 2300HS/2300HS

RS-232 Features

RS-232 Baud Rate

This feature selects the baud rate required for sending and receiving data.

To specify the RS-232 Baud Rate:

1. Scan the SWITCH bar code.

2. Scan the desired baud rate from the bar codes below and on the

immediately following pages. You’ll need to cover any unused bar

codes on this and the facing page to ensure that the scanner reads

only the bar code you intend to scan.

3. Complete the programming sequence by scanning the SWITCH

bar code.

RS-232 BAUD RATE = 1200

RS-232 BAUD RATE = 2400

NOTE

Single cable interfaces are limited to Baud Rate selections up to

19200. They cannot communicate at Baud Rates of 38400 and up.
