Magellan 2200VS User Manual

5-64 Magellan
TM
2200VS/2200VS and 2300HS/2300HS
Auxiliary Port Baud Rate
Specifies the baud rate of the auxillary port when operating in PIR/CT
mode.
To sp e cif y the Au x ili a r y Port Bau d Rate :
1. Scan the SWITCH bar code.
2. Scan the desired baud rate from the bar codes below and on the
immediately following pages. You’ll need to cover any unused bar
codes on this and the facing page to ensure that the scanner reads
only the bar code you intend to scan.
3. Complete the programming sequence by scanning the SWITCH
bar code.
AUXILIARY PORT BAUD RATE = 1200
AUXILIARY PORT BAUD RATE = 2400
NOTE
PIR/CT is a value-added feature which may not have been activated on
your model.

Magellan 2200VS Specifications

General

Scan Technology	Laser
Connectivity Technology	Wired
Light Source	Visible Laser Diode (VLD)
Operating Temperature	10° to 40° C (50° to 104° F)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Humidity	5% to 95% non-condensing
Interface	RS-232, USB
